Appserver Config (原remote config)方案 ===== ## 数据结构 三范式设计拆分 ```sql CREATE TABLE collections ( collection_id serial primary key, collection_name varchar(255), app_id varchar(16), created_at timestamp, updated_at timestamp ) ``` ```sql CREATE TABLE configs ( config_id serial primary key, collection_id integer, tag varchar(255) created_at timestamp, updated_at timestamp ) ``` ```sql CREATE TABLE commits ( commit_code serial primary key, latest bool, #to be removed config_id integer, description text, hash_value varchar(255), created_at timestamp, updated_at timestamp, url varchar(255) ) ``` table结构 ```sql CREATE TABLE public.appserver_config_latest ( id serial NOT NULL, app_id character varying(16), collection_name character varying(255), config_id character varying(16), commit_code integer, description text, hash_value text, tag text, created_at timestamp with time zone DEFAULT now(), updated_at timestamp with time zone DEFAULT now(), url text, operation_user text, CONSTRAINT appserver_config_latest_pkey PRIMARY KEY (id) ); CREATE UNIQUE INDEX ASCL_appid_collectionname_configid_idx ON appserver_config_latest (app_id, collection_name, config_id); ``` ```sql CREATE TABLE public.appserver_config_history ( id serial NOT NULL, app_id character varying(16), collection_name character varying(255), config_id character varying(16), commit_code integer, description text, hash_value text, tag text, created_at timestamp with time zone DEFAULT now(), updated_at timestamp with time zone DEFAULT now(), url text, operation_user text, CONSTRAINT appserver_config_history_pkey PRIMARY KEY (id) ); CREATE UNIQUE INDEX ASCH_appid_collectionname_configid_commitcode_idx ON appserver_config_history (app_id, collection_name, config_id, commit_code); ``` ```sql CREATE TABLE public.appserver_config_released ( id serial NOT NULL, app_id character varying(16), collection_name character varying(255), config_id character varying(16), commit_code integer, description text, hash_value text, tag text, created_at timestamp with time zone DEFAULT now(), updated_at timestamp with time zone DEFAULT now(), released_at timestamp with time zone DEFAULT now(), url text, operation_user text, CONSTRAINT appserver_config_released_pkey PRIMARY KEY (id) ); CREATE UNIQUE INDEX ASCR_appid_collectionname_configid_idx ON appserver_config_released (app_id, collection_name, config_id); ``` ```sql CREATE TABLE public.appserver_config_deletion_record ( deleted_id serial NOT NULL, app_id character varying(16), collection_name character varying(255), config_id character varying(16), commits integer, description text, tag text, created_at timestamp with time zone DEFAULT now(), deleted_at timestamp with time zone DEFAULT now(), url text, operation_user text, CONSTRAINT appserver_config_deletion_record_pkey PRIMARY KEY (deleted_id) ); CREATE INDEX ASCD_appid_collectionname_configid_idx ON appserver_config_deletion_record (app_id, collection_name, config_id); ``` ```sql CREATE TABLE public.appserver_config_collections ( collection_id serial, app_id character varying(16), collection_name character varying(40), created_at timestamp with time zone, updated_at timestamp with time zone, CONSTRAINT appserver_config_collections_pkey PRIMARY KEY (collection_id) ); CREATE UNIQUE INDEX ASCCollections_appid_collectionname_idx ON appserver_config_collections (app_id, collection_name) ``` ```go type config struct{ ID int `pg:"id,pk" json:"-"` CollectionName string `pg:"collection_name" json:"collection_name"` //1 ConfigID int `pg:"config_id" json:"config_id"` Description string `pg:"description" json:"description"` HashValue string `pg:"hash_value" json:"hash_value"` CommitCode int `pg:"commit_code" json:"commit_code"` Tag string `pg:"tag" json:"tag"` CreatedAt time.Time `pg:"created_at" json:"created_at"` UpdatedAt time.Time `pg:"updated_at" json:"updated_at"` ConfigFile struct{ Name string `json:"name"` URL string `json:"url"` Size int `json:"size"` Ext string `json:"ext"` CreatedAt time.Time `json:"created_at"` }`pg:"-" json:"config_file"` } type deletedRecord struct { tableName struct{} `pg:"appserver_config_deletion_record"` DeletedID int `pg:"deleted_id,pk" json:"deleted_id"` AppID string `pg:"app_id" json:"app_id"` CollectionName string `pg:"collection_name" json:"collection_name"` ConfigID string `pg:"config_id" json:"config_id"` Commits int `pg:"commits" json:"commits"` Tag string `pg:"tag" json:"tag"` Description string `pg:"description" json:"description"` URL string `pg:"url" json:"url"` OperationUser string `pg:"operation_user" json:"operation_user"` CreatedAt time.Time `pg:"created_at" json:"created_at"` DeletedAt time.Time `pg:"deleted_at" json:"deleted_at"` } type collectionModel struct { tableName struct{} `pg:"appserver_config_collections"` CollectionID string `pg:"collection_id,pk" json:"collection_id"` AppID string `pg:"app_id" json:"app_id"` CollectionName string `pg:"collection_name" json:"collection_name"` CreatedAt time.Time `pg:"created_at" json:"created_at"` UpdatedAt time.Time `pg:"updated_at" json:"updated_at"` Count int `pg:"-" json:"count"` } ``` 变化：1 1. 之前的形式是一个collection一张表，现在想要设计成一个表来保存所有collection的所有数据 ## 外部接口 > 以下接口全部为console的对外接口，特殊标识为to_be_deprecated是即将弃用的接口，server的接口也会在appserver config上线后被console取缔，所以不再在此列出。 > 另：appserver config的console接口全部是接收token访问的。 ### 01 GET {bp_console_domain}/appserver_config/app_id/{app_id} to_be_deprecated: {bp_console_domain}/remote_config/{app_id} 获取app下的所有collection name (app_id 由hostname获取) 示例输出： ```json { "appserver_config":{ "collections":[ "bytepower_test1", "bytepower_test2", ... ] } } ``` ### 02 GET {bp_console_domain}/appserver_config/app_id/{app_id}/collection/{collection_name} to_be_deprecated: {bp_console_domain}/remote_config/{app_id}/{collection_name} 获取{collection_name}下的config array response变化：之前array每个元素的多层json结构 改为了 扁平json结构的array 示例输出： ```json { "appserver_config":{ "collection_name":"bytepower_test", "configs":[ { "config_id": 1, "collection_name": "bytepower_test", "description": "test", "hash_value": "xxx", "latest": false, "commit_code": 1, "tag": "", "created_at": "2020-08-20 06:29:44.395+00", "updated_at": "2020-08-20 06:29:44.395+00", "config_file":{ "name": "1_1.json" "size": 122.95, "ext": "json", "url": "http://xxx/1_1.json", "created_at": "2020-08-20 06:29:44.395+00" } },{},{}... ] } } ``` ### 03 GET {bp_console_domain}/appserver_config/app_id/{app_id}/collection/{collection_name}/latest to_be_deprecated: {bp_console_domain}/remote_config/{app_id}/{collection_name}/latest 获取{collection_name}下各个最新版本config的array response变化：之前array每个元素的多层json结构 改为了 扁平json结构的array 示例输出： ```json { "appserver_config":{ "collection_name":"bytepower_test", "configs":[ { "config_id": 999, "collection_name": "bytepower_test", "description": "test", "hash_value": "xxx", "latest": true, "commit_code": 3, "tag": "", "created_at": "2020-08-20 06:29:44.395+00", "updated_at": "2020-08-20 06:29:44.395+00", "config_file":{ "name": "999_3.json" "size": 122.95, "ext": "json", "url": "http://xxx/999_3.json", "created_at": "2020-08-20 06:29:44.395+00" } },{},{}... ] } } ``` ### 04 GET {bp_console_domain}/appserver_config/app_id/{app_id}/collection/{collection_name}/config_id/{config_id}/latest to_be_deprecated: {bp_console_domain}/remote_config/{app_id}/{collection_name}/config_id/{config_id} 获取{collection_name}下最新的config 示例输入： 示例输出： ```json { "appserver_config":{ "collection_name":"bytepower_test", "configs":[ { "config_id": 1, "collection_name": "bytepower_test", "description": "test", "hash_value": "xxx", "latest": true, "commit_code": 2, "tag": "", "created_at": "2020-08-20 06:29:44.395+00", "updated_at": "2020-08-20 06:29:44.395+00", "config_file":{ "name": "1_2.json" "size": 122.95, "ext": "json", "url": "http://xxx/1_2.json", "created_at": "2020-08-20 06:29:44.395+00" } } ] } } ``` ### 05 GET {bp_console_domain}/appserver_config/app_id/{app_id}/collection/{collection_name}/count to_be_deprecated: {bp_console_domain}/remote_config/{app_id}/{collection_name}/count 获取{collection_name}下config的总数量 无变化 ### 06 PUT {bp_console_domain}/appserver_config/app_id/{app_id}/collection/{collection_name}/config_id/{config_id} to_be_deprecated: {bp_console_domain}/remote_config/{app_id}/{collection_name}/{config_id} 更新{collection_name}下最新的config 无变化 示例输入： ```json { "description":"new_description", "tag":"new_tag", "hash_value":"new_hash_value" } ``` 示例输出： ```json { "appserver_config":{ "collection_name":"bytepower_test", "configs":[ { "config_id": 999, "collection_name": "bytepower_test", "description": "new_description", "hash_value": "new_hash_value", "latest": true, "commit_code": 4, "tag": "new_tag", "created_at": "2020-08-20 06:29:44.395+00", "updated_at": "2020-08-21 11:29:44.395+00", "config_file":{ "name": "999_4.json" "size": 122.95, "ext": "json", "url": "http://xxx/999_4.json", "created_at": "2020-08-20 06:29:44.395+00" } } ] } } ``` ### 07 POST {bp_console_domain}/appserver_config/revoke to_be_deprecated: {bp_console_domain}/remote_config/revoke 将config_id的配置revoke到哪个commit_id的版本 示例输入： ```json { "app_id":xxx, "collection_name":"bytepower_test", "commit_code":3, "config_id":999 } ``` 示例输出： ```json { "appserver_config":{ "collection_name":"bytepower_test", "configs":[ { "config_id": 999, "collection_name": "bytepower_test", "description": "xxx", "hash_value": "xxx", "latest": true, "commit_code": 5, "tag": "new_tag", "created_at": "2020-08-20 06:29:44.395+00", "updated_at": "2020-08-21 11:29:44.395+00", "config_file":{ "name": "999_5.json" "size": 122.95, "ext": "json", "url": "http://xxx/999_5.json", "created_at": "2020-08-21 11:29:44.395+00" } } ] } } ``` ### 08 POST {bp_console_domain}/appserver_config/commit/single to_be_deprecated: {bp_console_domain}/remote_config/commit/single 创建一条新的config 示例输入： ```http POST {bp_console_domain}/appserver_config/commit/single HTTP/1.1 Host: xxx Content-Length: xxx Content-Type: multipart/form-data; boundary=----WebKitFormBoundaryabcd ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="app_id" app1 ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="collection_name" bytepower_test ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="config_id" 999 ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="description" whatever ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="hash_value" whatever ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="tag" whatever ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="config_file"; filename="xxx.json" Content-Type: <Content-Type header here> (data) ----WebKitFormBoundaryabcd ``` 示例输出： ```json { "appserver_config":{ "collection_name":"bytepower_test", "configs":[ { "config_id": 999, "collection_name": "bytepower_test", "description": "whatever", "hash_value": "whatever", "latest": true, "commit_code": 5, "tag": "whatever", "created_at": "2020-08-20 06:29:44.395+00", "updated_at": "2020-08-20 06:29:44.395+00", "config_file":{ "name": "999_5.json", "size": 122.95, "ext": ".json", "url": "http://xxx/999_5.json", "created_at": "2020-08-20 06:29:44.395+00" } } ] } } ``` ### 09 GET {bp_console_domain}/appserver_config_file/app_id/{app_id}/collection/{collection_name}/config_id/{config_id}/latest to_be_deprecated: {bp_console_domain}/remote_config_file/{app_id}/{collection_name}/{config_id} 获取{collection_name}下最新config的文件content 示例输出： ``` file_content... ``` ### 10 GET {bp_console_domain}/appserver_config_file/app_id/{app_id}/collection/{collection_name}/config_id/{config_id}/{commit_code} to_be_deprecated: {bp_console_domain}/remote_config_file/{app_id}/{collection_name}/{config_id}/{commit_code} 获取{collection_name}下指定commit_code的config文件content 示例输出： ``` file_content... ``` ### 11 POST {bp_console_domain}/appserver_config/commit/multiple to_be_deprecated: {bp_console_domain}/remote_config/commit/multiple 创建多条新的config prerequisite: * 创建一个描述文件，并命名为manifest.json，描述内容为即将上传的每个config file的属性，详见下示例。(description, tag, hash_value都不是mandatory) * 将描述文件与所有需要上传的文件一起以zip格式压缩成包。 * 压缩包文件的命名为文件的MD5 checksum，例如c371ad384e031619fc99b9338d847bc6.zip manifest.json ```json [ { "collection_name":"walk_configs", "config_id":"16", "description":"test", "tag":"xx", "file_name":"16.json" }, { "collection_name":"walk_configs", "config_id":"15", "description":"新增配置15", "hash_value":"xx", "file_name":"15.json" } ] ``` 示例输入 ```http POST (console)/appserver_config/commit/multiple HTTP/1.1 Host: xxx Content-Length: xxx Content-Type: multipart/form-data; boundary=----WebKitFormBoundaryabcd ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="app_id" app1 ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="zip_file"; filename="xxx.zip" Content-Type: <Content-Type header here> (data) ----WebKitFormBoundaryabcd ``` 示例输出 ```json { "appserver_config": { "configs": [ { "collection_name": "walk_configs", "commit_code": 3, "config_file": { "name": "16_3.json", "url": "https://localhost:5671/remote_config_file/APPQRHLW6JOXCLQ3/walk_configs/16/3" }, "config_id": 16, "created_at": "2021-02-09T18:13:13.00946+08:00", "description": "test", "hash_value": "0272f9b7fe677931b2a4131e6489ec1042ef63142714b0e2d65ed79615dec98a", "latest": true, "tag": "", "updated_at": "2021-02-09T18:13:13.00946+08:00" }, { "collection_name": "walk_configs", "commit_code": 3, "config_file": { "name": "15_3.json", "url": "https://localhost:5671/remote_config_file/APPQRHLW6JOXCLQ3/walk_configs/15/3" }, "config_id": 15, "created_at": "2021-02-09T18:13:13.220874+08:00", "description": "新增配置15", "hash_value": "fb017fb434d6165fc127683f132f5721cc23becbe0b32210bf4d342a53cd14ff", "latest": true, "tag": "", "updated_at": "2021-02-09T18:13:13.220874+08:00" } ] } } ``` ### 12 POST {bp_console_domain}/appserver_config_file/app_id/{app_id}/collection/{collection_name} to_be_deprecated: {bp_console_domain}/remote_config_file/{app_id}/{collection_name} 根据请求体中的config id，获取包含多个config file的压缩包。 示例输入 ```json [ "16","15" ] ``` 输出为一个zip包，以md5 checksum命名，包内包含manifest描述文件。 ### 13 GET {bp_console_domain}/appserver_config/app_id/{app_id}/collection/{collection_name}/released 获取指定collection下的所有released的config信息 示例输出： ```json { "appserver_config":{ "configs":[ ... ] } } ``` ### 14 GET {bp_console_domain}/appserver_config_file/app_id/{app_id}/collection/{collection_name}/config_id/{config_id}/released 获取指定collection下指定config_id的released文件内容 示例输出： ``` file_content ... ``` ## console页面接口 ### 页面接口prefix {console_domain}/api/workspace/{spaceID}/application/{appID}/appserver_config ### 01 GET ~/collection 获取App下所有collection，用来load下拉菜单 ### 02 GET ~/collection?page={page_number} 获取App的collection页，每页大小为10 ### 03 POST ~/collection 创建新的collection body: ```json { "collection_name":xxx } ``` ### 04 DELETE ~/collection 删除一个collection body: ```json { "collection_id":xxx } ``` ### 05 PUT ~/collection 更新一个collection的命名 body: ```json { "collection_id":xxx, "collection_name":xxx } ``` ### 05.extra POST ~/check_collection_name 查看collection name是否已存在 body: ```json { "collection_name":xxx } ``` ### 06 GET ~/config_base_page?collection_name={collection_name}&page={page_number} 获取一个collection下的config页面 ### 07 GET ~/config_detail_page?collection_name={collection_name}&config_id={config_id}&page={page_number} 获取一个config的详细信息页面 ### 08 POST ~/config 上传一个新的config ```http POST (console)/workspace/SPACEXUFLNY2NZS4IS/application/APPYXGMNY2NC4WGN/ HTTP/1.1 Host: xxx Content-Length: xxx Content-Type: multipart/form-data; boundary=----WebKitFormBoundaryabcd ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="collection_name" test_bytepower_1 ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="config_id" 567 ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="description" xxx ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="hash_value" xxx ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="tag" xxx ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="config_file"; filename="xxx.json" Content-Type: <Content-Type header here> (data) ----WebKitFormBoundaryabcd ``` ### 09 PUT ~/config 更新一个config的meta信息 ```json { "collection_name":xxx, "config_id":xxx, "description":xxx, "tag":xx } ``` ### 10 DELETE ~/config 删除一个config的所有历史 ```json { "colleciton_name":xxx, "config_id":xxx } ``` ### 11 POST ~/configs 上传一个zip包来进行批量上传 *注意，zip包的名需要以改包的md5命名。包内不再需要manifest文件来描述，但是文件名需为数字，也就是config_id ```http POST (console)/workspace/SPACEXUFLNY2NZS4IS/application/APPYXGMNY2NC4WGN/ HTTP/1.1 Host: xxx Content-Length: xxx Content-Type: multipart/form-data; boundary=----WebKitFormBoundaryabcd ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="collection_name" xxx ----WebKitFormBoundaryabcd Content-Disposition: form-data; name="zip_file"; filename="md5.zip" Content-Type: <Content-Type header here> (data) ----WebKitFormBoundaryabcd ``` ### 12 GET ~/config_file?collection_name={colleciton_name}&config_id={config_id}&commit_code={commit_code} 指定collection name，config id与commit code来获取该记录的config file ### 13 POST ~/release 发布一个config ```json { "collection_name":xxx, "config_id":xxx } ``` ### 14 POST ~/release_all 将colleciton下的config全部发布 ```json { "collection_name":xxx } ``` ### 15 GET ~/deleted_config_page?page={page_number} 获取已删除config的页面 ### 16 GET ~/deleted_config_file?deleted_id={deleted_id} 根据deleted_id获取已被删除的config文件zip包。 ## 压测数据（stage） 发压受压同机 （接口01）  发压受压不同机（发压机为本机） （接口01）  发压受压同机 （接口02）  发压受压不同机（发压机为本机） （接口02）  发压受压同机 （接口03）  发压受压不同机（发压机为本机） （接口03）  [pprof](/uploads/upload_f35a617061487c69c6ea9bbc98b770cb.svg) ## config文件管理 config文件通过s3来保存 在s3上的dev-bytepower bucket，bucket下{app_id}/remote_config文件夹中每个文件夹代表一个collection，不断更迭版本的config文件存放在这个文件夹下, config文件命名：{config_id}_{commit_code}.{ext} config文件保存在s3上的url示例: https://dev-bytepower.s3.cn-northwest-1.amazonaws.com.cn/app_data/{app_id}/remote_config/bytepower_test/999_3.json ```s3 >bucket >app_data >app_id >remote_config >collections >files dev-bytepower/ app_data/ app_id/ remote_config/ coin/ bytepower_test/ amber_configs/ 1_1.json 2_1.json 2_2.json 2_3.json ... amber_satisfaction/ amber_withdraw_configs/ ... ``` ## 向appserver config过渡keynote ### 过渡期： 1. database -- 将原有的两个table：remote_config_latest和remote_config_history的数据copy到新table： appserver_config_latest和appserver_config_history下 2. s3 -- remote config文件夹下的文件保持不动，appserver config上线后，新上传的config文件会全部保存至appserver config文件夹下  3. response -- 从兼容性出发，过渡期的response会从旧的格式（remote_config为key的json）变更为新的格式（有remote_config和appserver_config两个key的json，且内部内用完全相同） ```json { "remote_config":{ "我是内容" } } ``` ```json { "remote_config":{ "我是内容" }, "appserver_config":{ "我是内容" } } ``` 4. api接口 -- 旧的remote_config提供的api接口都可以照常使用直至过渡期结束，但是写入的记录都会记录到新的table和文件路径中去。 ### 不忘初心的收尾期 1. database -- 将copy到新table下的remote_config时期的数据，其中s3路径信息更新至appserver_config。 2. s3 -- 将remote_config文件夹下的config file全部迁移至appserver_config文件夹中，使db中的记录保持有效性。 3. response -- 由`remote_config`与`appserver_config`并存的格式变为只有`appserver_config`为key的格式。 4. api接口 -- bp server的endpoint不再提供，bp console的/remote_config/... endpoint移除，只留/appserver_config/... ## BytePower Server 接口 - 获取最新 Released 配置信息 ``` {server_domain}/bp/server/appserver_config/{collection_name}/latest ## 示例 Appserver Config Get Released curl "http://test-app.bp-server.atcloudbox.com/bp/server/appserver_config/test_collection_2/latest" \ -H 'Accept: application/vnd.bytepower.v1+json' \ -H 'X-BytePower-Application-Id: APPJMPKTO4NID2KT' ```
